SPECIFICATIONS
- Chassis: HME 1871 MFD 100” Wide
- Cummins L9 450 HP Motor
- Allison EVS 3000 Transmission
- Front Disc Brakes
- 19k Hendrickson Steertec Front Axle
- 27k Reyco Granning Rear Axle
- Hale Q-Max 1,500 GPM Pump
- 1,000 Gallon Tank
- Standard NFPA Hose Bed
- Hale Pump Module
- Two-Piece Windshield
- *Select Available Upgrades
| COMPARTMENTATION | ||||||
|---|---|---|---|---|---|---|
| BEHIND DOOR | CLEAR OPENING | |||||
| COMPT. | WIDTH | HEIGHT | DEPTH | DOOR WIDTH | DOOR HEIGHT | COMPT. VOLUME |
| L1 | 56” | 63” | 24” | 47” | 55” | 49 FT3 |
| L2 | 52” | 33” | 24” | 49.5” | 24” | 23.8 FT3 |
| L3 | 51” | 63” | 24” | 47.5” | 55” | 44.6 FT3 |
| R1 LOWER: | 56” | 30” | 24” | 47” | 55” | 23.3 FT3 |
| R1 UPPER: | 56” | 33” | 12” | 47” | 55” | 12.8 FT3 |
| R2 | 52” | 33” | 12” | 49.5” | 24” | 11.9 FT3 |
| R3 LOWER | 51” | 30” | 24” | 47.5” | 55” | 21.3 FT3 |
| R3 UPPER | 51” | 33” | 12” | 47.5” | 55” | 11.7 FT3 |
| RR1: | 48” | 63” | 22” | 31” | 48” | 38.5 FT3 |
